VMware 5V0-62.22 VMware Workspace ONE 21.X UEM Troubleshooting Specialist Exam Practice Test

The administrator at the Logistics OG has the Console Administrator role, which means they can manage all the smart groups that are created in their own OG or below1. Therefore, they can manage the Logistics Team Central Office and Midwest Rugged smart groups, which are both created in the Logistics OG. They cannot manage the VMBeans (VMBeans), Sales Android Device, and Sales Laptop smart groups, which are created in higher OGs.

The feature that is included in VMware Workspace ONE Assist in Attended Mode is view and export detailed device information, access activity logs, run commands, and manage files. This feature allows the administrator to remotely access the device screen and perform various actions to troubleshoot issues or assist the user. The administrator can also view the device details, such as battery level, network status, memory usage, and so on. The administrator can also access the device logs, run commands such as ping or traceroute, and manage the device files1.

The most likely cause of this issue is that the VMware Workspace ONE administrator set “RAM Required” for the application in the “Details” tab options. The “RAM Required” option specifies the minimum amount of RAM needed for the application to run on Windows devices. If some devices do not meet this requirement, they will not be able to complete the installation of the application. The administrator should check and adjust the “RAM Required” option for the application according to the device capabilities.

The VMware Workspace ONE Assist Agent mode that will meet this requirement is Attended Mode. Attended Mode is a mode that requires user consent and presence for remote sessions. The user can see and control the remote session, and can also pause or end it at any time for enhanced privacy2. Attended Mode also allows the user to approve or deny many of the remote actions, such as file transfer, command execution, or device information access2.

The option that is available for Unified Access Gateway to export a collection of all logs is using the UAG-log-archive.zip download button from the Support Settings section in the UAG Admin UI. This ZIP file contains all logs from the Unified Access Gateway appliance, such as system information, network configuration, edge service logs, and so on4. This option can help troubleshoot any issues or errors related to Unified Access Gateway deployment and operation.

The most likely cause of this issue is that the VPN payload in the Android device profile is configured incorrectly in UEM. The VPN payload defines how devices connect to the VMware Tunnel edge service and access internal resources. If the VPN payload is incorrect, the devices will not be able to establish a VPN connection with the VMware Tunnel edge service and access server resources on the organization’s internal network. The administrator should review and correct the VPN payload settings in UEM.

The console page that would confirm a potential configuration change is Monitor > Reports & Analytics > Events > Console Events. This page allows the administrator to view and filter the events that occurred in the Workspace ONE UEM console, such as configuration changes, user actions, system errors, and so on. The administrator can use this page to find out if a configuration was enabled by mistake that caused the error.

The organization’s Apple Push Notification certificate expired. The Apple Push Notification certificate is a certificate that allows Workspace ONE UEM to communicate with iOS devices using push notifications. Push notifications are required for iOS devices to check in and receive email configuration profiles from Workspace ONE UEM. If the Apple Push Notification certificate expires or becomes invalid, iOS devices will not be able to check in or receive email configuration profiles, and their email inbox will fail to load. The administrator should check and renew the Apple Push Notification certificate if needed.

An organization administrator changed the assignment of the application to the customer OG (organization group). The assignment of an application determines which devices can see and install the application from the Workspace ONE Catalog. If an organization administrator changed the assignment of an application from a lower OG (such as customer) to a higher OG (such as global), it may affect the visibility and availability of the application for some devices in lower OGs. The administrator should check and restore the assignment of the application to the customer OG if needed.

The service that the organization administrator has direct control over to enable verbose logging to troubleshoot this issue is ACC (AirWatch Cloud Connector) service. ACC is a service that integrates Workspace ONE UEM with internal enterprise systems, such as Active Directory or Certificate Authority. ACC enables Workspace ONE UEM to use internal resources without exposing them to the Internet. If some users are unable to enroll their devices using their Active Directory accounts, it could indicate that there is a problem with ACC configuration, connectivity, or synchronization. Enabling verbose logging for ACC can help identify and troubleshoot the root cause of the issue.

The iOS specific requirement that should be reviewed is APNs certificate validity. APNs (Apple Push Notification service) certificate is a certificate that allows Workspace ONE UEM to communicate with iOS devices using push notifications. If the APNs certificate expires or becomes invalid, iOS devices will not be able to receive push notifications or check in with Workspace ONE UEM. The administrator should check and renew the APNs certificate if needed.

 The most likely cause of this issue is that the application installation file is corrupted. A corrupted file may cause the application installation to fail or abort on the devices4. The administrator should verify the integrity of the application installation file and upload a new file if needed.

The misconfiguration that would be causing this behavior is AWCM Persistence is not correctly configured. AWCM Persistence is a setting that ensures that devices maintain a consistent connection with the same AWCM server in a load-balanced environment. If AWCM Persistence is not correctly configured, devices may be bounced between different AWCM servers and cause enrollment failures or communication errors. The administrator should check and configure AWCM Persistence properly.

The connectivity that should be investigated to restore ACC functionality is from the ACC to the Active Directory server. The error message in the ACC logging indicates that the ACC cannot connect to the Active Directory server due to a network error. This could be caused by firewall settings, proxy settings, network configuration, or other factors that prevent the ACC from communicating with the Active Directory server. The administrator should check and resolve these issues to restore the ACC functionality2.

The possible root cause of this issue is that the Secure Email Gateway server is unable to connect to the Exchange server. This could be due to network issues, firewall settings, or authentication problems. If the Secure Email Gateway server cannot communicate with the Exchange server, it will not be able to deliver email to the newly enrolled devices. The previously enrolled devices may still be able to receive email because they have cached credentials or sessions with the Exchange server. The users who reported this issue are able to access their email through OWA on their computers because OWA does not rely on the Secure Email Gateway server.

The tunnel_snap utility can help troubleshooting by gathering all the necessary component log files that may be required during the process. This utility is available on both Linux and Windows versions of VMware Tunnel1. The tunnel_snap utility collects logs from the following components:

• VMware Tunnel service
• Per-App Tunnel service
• Proxy service
• Content Gateway service
• VMware Tunnel configuration files
• System information
• Network information The other options are not valid utilities for VMware Tunnel.

The service that the organization administrator should enable verbose logging to resolve this issue is ACC (AirWatch Cloud Connector) service. ACC is a service that integrates Workspace ONE UEM with internal enterprise systems, such as Active Directory or Certificate Authority. ACC enables Workspace ONE UEM to use internal resources without exposing them to the Internet. If “Test Connection” fails when configuring a shared SaaS Workspace ONE UEM environment to use an internal Active Directory Certificate Authority, it could indicate that there is a problem with ACC configuration, connectivity, or synchronization. Enabling verbose logging for ACC can help identify and troubleshoot the root cause of the issue4.

The console page that should be used to see this information is Devices > List View > Device Details View > More > Troubleshooting. This page allows the administrator to view various information about a specific device, such as profile status, application status, device-related logging, compliance status, commands history, and so on. This page can help troubleshoot issues related to device enrollment, configuration, management, and communication.
