USGBC LEED-AP-BD+C LEED AP Building Design + Construction (LEED AP BD+C) Exam Practice Test

In the Integrative Process, the Owner’s Project Requirements (OPR) should be created during the predesign phase and edited throughout the project (C). The OPR documents the owner’s goals and objectives, guiding design decisions to align with these priorities. Updating the OPR as necessary ensures that project design and construction remain aligned with the owner’s vision and LEED requirements.

Detailed Explanation:

Exemplary Performance for Rainwater Management requires achieving both Option 1 (Percentile of Rainfall Events) and Option 2 (Natural Land Cover Conditions). This demonstrates a superior level of stormwater management by addressing both the volume and quality of runoff, aligning with LEED’s goals of reducing stormwater impacts on surrounding ecosystems and water infrastructure.

This is the requirement for the Indoor Environmental Quality prerequisite Environmental Tobacco Smoke Control, which applies to all LEED BD+C rating systems. The intent is to prevent or minimize exposure of building occupants, indoor surfaces, and ventilation air distribution systems to environmental tobacco smoke. The no-smoking signage must explicitly state the 25 ft. (8 m) limit and communicate the no-smoking policy to occupants.

Detailed Explanation:

The Basis of Design (BOD) outlines the project design decisions and criteria, linking them to the Owner’s Project Requirements (OPR). LEED requires this documentation to demonstrate alignment between the owner’s goals and the building design, ensuring that sustainability objectives are met throughout the project lifecycle.

Detailed Explanation:

The project must meet the more stringent requirement, which in this case is 500 CFM (14.1 CMM) as per the local code. LEED Enhanced Indoor Air Quality prerequisites and credits prioritize compliance with the highest applicable ventilation standards to improve indoor air quality and occupant comfort.

ENERGY STAR® (C) provides tools recognized by the U.S. Green Building Council (USGBC) that assist with energy management strategies, benchmarking, and procurement guidelines. ENERGY STAR offers resources for energy performance benchmarking, operational efficiency, and product standards, which help project managers optimize energy use in line with LEED requirements. Green Seal (A) and SCAQMD (B) focus on materials and emissions, while SMACNA (D) provides guidelines for air quality management.

According to the LEED v4: Building Design + Construction Guide, the Location and Transportation Credit, Bicycle Facilities has two options: Option 1. Bicycle Network and Storage and Option 2. Reduced Parking Footprint. Option 1 requires the project to provide short-term bicycle storage for at least 2.5% of all peak visitors, and long-term bicycle storage for at least 5% of all regular building occupants. Short-term bicycle storage must be within 100 ft (30 m) walking distance of any main entrance, and long-term bicycle storage must be within 300 ft (90 m) walking or bicycling distance of any functional entry. Option 2 requires the project to provide short-term bicycle storage for at least 2.5% of all peak visitors, and long-term bicycle storage for at least 5% of all regular building occupants, and also reduce the total parking capacity by at least 20% from the base ratios. Both options can earn one point under this credit1.

If a commercial building is considered to have 100 peak visitors in a day, the minimum number of short-term bicycle storage spaces that must be provided to earn one point under Option 1 or Option 2 is 2.5% of 100, which is 2.5, rounded up to 3. However, the project must also provide long-term bicycle storage for at least 5% of all regular building occupants, which is not given in the question. Therefore, the correct answer is C, five, which is the minimum number of short-term bicycle storage spaces that must be provided to earn one point under Option 1 or Option 2, regardless of the number of regular building occupants. References: LEED v4: Building Design + Construction Guide, Location and Transportation Credit, Bicycle Facilities, Requirements1

Using economizer strategies (A) can offset the additional energy required to increase ventilation. Economizers allow the HVAC system to bring in cooler outdoor air when conditions permit, thus reducing mechanical cooling needs. This method aligns with LEED’s goals for energy efficiency while maintaining indoor air quality. High MERV filters (B) may increase energy usage due to airflow resistance, and reducing duct size (D) can limit airflow efficiency, counteracting ventilation improvements.

Including the material requirements in the project specifications (D) ensures that all project team members are aware of and prioritize materials compliant with the Materials and Resources (MR) Credit: Building Product Disclosure and Optimization. Clearly defined specifications communicate the importance of sustainability criteria, such as environmental product declarations and sourcing. Whole-building life-cycle analysis (C) is part of separate LEED credits and doesn’t directly influence material prioritization by the team.

This option allows the project to comply with the minimum energy performance prerequisite by following the prescriptive recommendations of the ASHRAE 50% Advanced Energy Design Guide (AEDG) for the applicable building type and climate zone1. This option simplifies the decision making and analysis process by providing clear and specific guidance on how to achieve 50% energy savings compared to the baseline standard2. This option also reduces the need for energy modeling and documentation, which can save time and money for the project3.

Install an on-site photovoltaic array

Installing an on-site photovoltaic array is a direct method to produce renewable energy on the project site, which can be used to achieve points under the Energy Atmosphere Credit for Renewable Energy Production. Additionally, it contributes to optimizing energy performance by generating clean electricity on-site and reducing the need for energy from non-renewable sources.

Sustainable Sites (SS) Credit: Site Development - Protect or Restore Habitat encourages projects to use native or adapted vegetation to restore natural habitats and support local biodiversity.

Using non-native or non-adapted plants negatively impacts this credit because these plants often require excessive irrigation, fertilizers, or pesticides, which can harm local ecosystems.

Vegetated roofs (green roofs) are eligible for this credit, but only if they use native or adapted plant species.

Heat Island Reduction (Option C) focuses on materials and shading, not plant selection.

Light Pollution Reduction (Option D) relates to outdoor lighting, not vegetation choices.

The use of non-native plants most directly affects habitat restoration efforts, making Option B the correct answer.

(Source: Official LEED BD+C Reference Manual)

The surrounding residential density is calculated by dividing the total number of dwelling units by the total residential land area. In this case, it would be 780 dwelling units divided by 60% of 130 acres, which equals approximately 13 dwelling units per acre (or 32 dwelling units per hectare).

The nonresidential density, or Floor Area Ratio (FAR), is calculated by dividing the total nonresidential building floor area by the total nonresidential land area. In this case, it would be 1,600,000 ft² divided by 40% of 130 acres, which equals a FAR of approximately 0.47.

These calculations are used when attempting to achieve the Location and Transportation Credit, Surrounding Density and Diverse Uses, under the LEED AP BD+C V4 rating system.

Detailed Explanation:

Incorporating rooftop solar panels addresses glare concerns effectively by replacing reflective surfaces with photovoltaic modules while simultaneously supporting LEED credits for renewable energy production. This strategy avoids negative impacts on other credits, such as Heat Island Reduction or Energy Performance, and contributes positively to overall project sustainability.

USGBC’s vision for using LEED internationally is to promote green building practices that are globally applicable, locally relevant, and culturally sensitive1. To achieve this vision, USGBC provides opportunities for alternative compliance paths (ACPs) that meet the unique needs of a particular region, such as climate, codes, standards, market conditions, and priorities2. ACPs are modifications or additions to existing LEED credits or prerequisites that recognize regional differences and allow for more flexibility and applicability of LEED3. ACPs are developed by USGBC in collaboration with local green building councils, experts, and stakeholders, and are reviewed and approved by the LEED Steering Committee3. ACPs are available for various regions and countries, such as China, India, Brazil, Europe, and Canada2.

Detailed Explanation:

Regional Priority credits address environmental issues specific to a project’s geographic location. These credits encourage project teams to focus on local priorities, such as water conservation in arid regions or stormwater management in flood-prone areas, making sustainability efforts more context-sensitive.

A flexible dress code that permits seasonally appropriate clothing can promote both energy efficiency and thermal comfort in a building. This is because it allows occupants to adjust their clothing to the indoor and outdoor temperature variations, reducing the need for excessive heating or cooling. It also enhances the occupants’ satisfaction and productivity by allowing them to choose comfortable clothing. Surveying occupants about their comfort can help identify and address thermal comfort issues, but it does not necessarily improve energy efficiency. Providing individual space heaters can increase energy consumption and create thermal discomfort for other occupants. Turning off the lights after cleaning can save some energy, but it does not affect thermal comfort.

The Acoustic Performance credit under the LEED BD+C: Healthcare rating system addresses the acoustic environment in healthcare spaces. It requires strategies that reduce noise levels, control background noise, and provide sound privacy. The documents that would best inform this decision are:

Airport flyover maps: These can help determine the level of external noise intrusion into the building, which can affect the acoustic environment.

Mechanical plans: These can provide information about the location and type of mechanical equipment, which can be a source of internal noise.

Wall sections: These can provide information about the construction of the walls, including materials and assemblies, which can affect sound transmission between spaces1.

Quality views are defined in LEED as those which consist of multiple elements of nature, weather, or movement that allow for a connection beyond the interior space. Views that allow a clear line of sight to the exterior via vision glazing, with a view factor of 3 or greater, qualify for this credit. Fixed glazing in common spaces can also contribute to this credit.

The rail line station construction completion date is needed when determining whether the rail line station can contribute to Location and Transportation Credit, Access to Quality Transit. This is because the credit requires that the transit service must be existing or planned to be in operation within two years of the project’s occupancy1. Discounted rail pass availability, connections to transfer routes, and passenger capacity are not relevant for this credit1.

A rainwater harvesting system on site could be recognized in the Sustainable Sites Credit, Rainwater Management and the Water Efficiency Credit, Indoor Water Use Reduction. The Sustainable Sites Credit, Rainwater Management rewards projects that reduce runoff volume and improve water quality by replicating the natural hydrology and water balance of the site1. A rainwater harvesting system can help achieve this by capturing and reusing rainwater on site2. The Water Efficiency Credit, Indoor Water Use Reduction rewards projects that reduce indoor water consumption by installing water-efficient fixtures and fittings3. A rainwater harvesting system can help achieve this by providing an alternative source of water for non-potable uses such as toilet flushing and irrigation4.

The other options are not correct. The Water Efficiency Credit, Water Metering does not recognize rainwater harvesting systems, but rather requires projects to install permanent water meters that measure the total potable water use for the building and grounds. The Water Efficiency Prerequisite, Outdoor Water Use Reduction does not recognize rainwater harvesting systems, but rather requires projects to reduce outdoor water consumption by using plant species that are native or adapted to the region and by using irrigation systems that are efficient and properly controlled. The Water Efficiency Prerequisite, Indoor Water Use Reduction does not recognize rainwater harvesting systems, but rather requires projects to reduce indoor water consumption by 20% from the baseline by installing water-efficient fixtures and fittings.

The correct answer is D. critically reviewed life-cycle assessment conforming to ISO 14044. This is because:

•Option 1 of this credit requires the use of products that have environmental product declarations (EPDs), which are documents that provide information about the environmental impact of a product throughout its life cycle1.

•EPDs are based on life-cycle assessments (LCAs), which are systematic analyses of the environmental aspects and potential impacts of a product from raw material extraction to disposal2.

•LCAs must conform to the international standard ISO 14044, which specifies the principles and framework for conducting and reporting LCAs3. LCAs must also be critically reviewed by an independent panel of experts to ensure their validity and reliability4.

•The other options are not relevant for this credit. FSC certification is a label that indicates that a wood product comes from a well-managed forest5. Cradle-to-cradle certification is a label that indicates that a product is designed for circular economy, with minimal waste and toxicity. CSR is a report that discloses the social and environmental performance of a company.

According to the LEED v4: Building Design + Construction Guide, the owner or an owner’s representative must be a member of the integrated project team for the Integrative Process Prerequisite, Integrative Project Planning and Design. The owner or an owner’s representative is responsible for establishing the project’s vision, goals, budget, and schedule, as well as defining the owner’s project requirements (OPR) and participating in the design charrettes and reviews1. The owner or an owner’s representative also plays a key role in ensuring the continuity and alignment of the project’s performance and environmental objectives throughout all phases of the project1.

The other choices are not mandatory members of the integrated project team, although they may be involved in the integrative process depending on the project’s scope and needs. The general contractor is typically hired after the design phase and may not be involved in the predesign and schematic design analyses required by the prerequisite1. A LEED AP is a professional who has demonstrated knowledge and experience in applying the LEED rating system, but is not required to be part of the integrated project team, although it is recommended and rewarded by the LEED credit, Integrative Process1. The project’s mechanical engineer is one of the possible design consultants who may contribute to the integrative process, especially for the energy-related systems analysis, but is not required to be part of the integrated project team1.

To meet the Indoor Environmental Quality (IEQ) Prerequisite: Minimum Acoustic Performance for classrooms, sound pressure level measurements should be taken under conditions that reflect typical classroom use without occupants, ensuring accuracy in assessing HVAC background noise levels. Furnished, no occupants, HVAC operating at typical level (C) is the correct testing setup, as it accounts for sound absorption by furniture but excludes ambient noise from people. This setup provides a more accurate measure of the background noise levels produced by HVAC systems, ensuring compliance with acoustic performance requirements for optimal learning environments.

The Owner’s Project Requirements (OPR) is the document that should be used to record the project goals to be used throughout the design of the project. The OPR is a written document that details the ideas, concepts, and criteria that are determined by the owner to be important to the success of the project1. The OPR is developed during the pre-design phase and is used as a basis for the design team to prepare the Basis of Design (BOD), which describes how the design of the building systems meets the OPR2. The OPR is also used to evaluate the design, construction, and commissioning of the project to ensure that the owner’s expectations are met3.

Under LEED BD+C Energy and Atmosphere (EA) Credit: Renewable Energy Production, renewable biofuels must be sustainably sourced and not contaminated.

Non-mill residue forestry biomass waste qualifies as renewable biofuel because it consists of untreated wood residues from sustainable forestry operations.

Municipal solid waste is not considered renewable due to its mixed content.

Wood coated with paints, plastics, or resins is not renewable as it contains harmful chemicals.

Animal waste is not explicitly recognized by LEED as a renewable fuel.

(Source: Official LEED BD+C Reference Manual)

A condenser water system with a cooling tower and condenser water pumps is classified as a system composed of discrete pieces of equipment that can be metered together for the purposes of Energy and Atmosphere Credit, Advanced Energy Metering. This is because the condenser water system is a single energy end use that serves a specific function and can be isolated from other systems1. HVAC air system, electrical lighting system, and water flow system are not considered as single energy end uses, but rather as multiple energy end uses that serve different functions and cannot be easily isolated2.

Food gardens may be included or excluded from the calculations for Water Efficiency Credit, Outdoor Water Use Reduction, as per the project team’s discretion. If included, food gardens must be calculated using 100% potable water. If excluded, food gardens must be irrigated with 100% captured rainwater, recycled graywater, or water treated and conveyed by a public agency specifically for nonpotable uses. References:

Outdoor Water Use Reduction credit in LEED BD+C: New Construction v4.1 - LEED v4.11

LEED v4 BD+C WE Guide2

The assembly U-value of a building envelope component is the overall rate of heat transfer through that component, taking into account the different materials and layers that make up the component. For example, the assembly U-value of a wall would include the effects of the insulation, framing, sheathing, cladding, air films, etc. The assembly U-value is different from the material U-value, which is the rate of heat transfer through a single material. For example, the material U-value of steel is much higher than the material U-value of glass, but the assembly U-value of a steel-framed window may be lower than the assembly U-value of a glass curtain wall, depending on the other factors involved.

If a transporter lacks chain-of-custody (CoC) certification for certified wood products, the design team should recalculate the percentage of certified wood and classify the affected wood as non-certified (B). This approach follows LEED's requirements for accurate reporting on certified materials. LEED requires all certified wood to maintain CoC certification from the forest to the project site, so any deviation affects credit calculations. Submitting a CIR (A) isn’t needed as the LEED rules are clear on this matter, and removal (D) may not be feasible or cost-effective.

LEED awards Innovation points for Exemplary Performance when a project significantly exceeds standard credit requirements.

Indoor Environmental Quality (IEQ) Credit: Low-Emitting Materials qualifies for an Innovation point if a project achieves additional thresholds for compliance.

Daylight (Option A) does not have an Exemplary Performance pathway.

Minimum Indoor Air Quality Performance (Option C) is a prerequisite, so it cannot earn an Innovation point.

Acoustic Performance (Option D) also does not qualify for Exemplary Performance points.

Low-Emitting Materials (Option B) is eligible for Exemplary Performance, making it the correct answer.

(Source: Official LEED BD+C Reference Manual)

The Location and Transportation Credit, Access to Quality Transit requires projects to locate within walking distance of existing or planned transit stops that provide access to quality transit service1. Quality transit service is defined as transit service that meets the minimum weekday and weekend headways (time between vehicles) and hours of operation listed in Table 1 of the credit requirements2. According to Table 1, the minimum weekday headway for bus service is 15 minutes, and the minimum weekday headway for rail service is 10 minutes. The minimum weekend headway for both bus and rail service is 30 minutes. The minimum hours of operation for both bus and rail service are 6 a.m. to 8 p.m. on weekdays and 8 a.m. to 6 p.m. on weekends2. In addition, the credit requires projects to locate within a 1/4 mi. (0.40 km) walking distance of bus, streetcar, or rideshare stops or within a 1/2 mi. (0.80 km) walking distance of bus rapid transit stops, light or heavy rail stations, commuter rail stations, or ferry terminals1.

Option A does not represent quality transit service because it only has two bus lines that may not meet the minimum headway and hours of operation requirements. Option C does not represent quality transit service because it is beyond the maximum walking distance of 1/2 mi. (0.80 km) for rail stations. Option D does not represent quality transit service because it is a private shuttle bus that does not qualify as a public transportation service, and it provides hourly service that does not meet the minimum headway requirements. Option B represents quality transit service because it has a rail station that is within the maximum walking distance of 1/2 mi. (0.80 km) from the project building, and it has one train line that operates Monday through Sunday, which implies that it meets the minimum headway and hours of operation requirements.

The Consortium for Energy Efficiency (CEE) Tier 3A standard applies to water-efficient appliances, such as dishwashers, clothes washers, and commercial kitchen equipment. It is recognized in LEED BD+C for improving indoor water efficiency.

CEE Tier 3A focuses on high-efficiency appliances that meet stringent water and energy performance requirements.

These appliances contribute to Water Efficiency (WE) credits in LEED by reducing potable water consumption.

Other options are unrelated to standard appliances for indoor water reduction:

GreenSeal pertains to environmental product certifications, including low-VOC materials.

ASHRAE 62.1-2010 relates to ventilation and indoor air quality standards.

ISO 14044-2006 addresses life cycle assessment (LCA) methodologies.

(Source: Official LEED BD+C Reference Manual)

A pilot credit identified by the LEED AP that is relevant to the project would be documented in LEED Online as an Innovation Credit. Pilot credits are proposed credits that are used to test and evaluate a strategy before they can be considered for incorporation into the LEED consensus process for approval by USGBC membership1. All other LEED v4 and v4.1 projects may register for pilot credits and pilot ACPs in LEED Online1.

For LEED BD+C Materials and Resources (MR) Credit: Building Product Disclosure and Optimization, teams must prioritize material selection based on environmental and sustainability attributes.

Including material requirements in project specifications ensures that all contractors, suppliers, and stakeholders follow the necessary sustainability criteria.

Selecting locally sourced materials (Option B) is beneficial, but it is not the primary focus of this credit.

Whole-building life-cycle analysis (Option C) is related to a different LEED credit (MR Credit: Whole-Building Life-Cycle Impact Reduction).

Procuring materials directly from raw suppliers (Option D) is not a LEED requirement and does not ensure compliance with disclosure and optimization requirements.

Option A is the correct choice because defining sustainability criteria in specifications helps ensure LEED-compliant materials are used throughout the project.

(Source: Official LEED BD+C Reference Manual)

According to the LEED v4: Building Design + Construction Guide, the 40/60 rule provides guidance for making a decision when several rating systems appear to be appropriate for a project. To use this rule, first assign a rating system to each square foot or square meter of the building, and then choose the most appropriate rating system based on the resulting percentages. The entire gross floor area of a LEED project must be certified under a single rating system and is subject to all prerequisites and attempted credits in that rating system, regardless of mixed construction or space usage type. If a rating system is appropriate for less than 40% of the gross floor area of a LEED project building or space, then that rating system should not be used. If a rating system is appropriate for more than 60% of the gross floor area of a LEED project building or space, then that rating system should be used. If an appropriate rating system falls between 40% and 60% of the gross floor area, project teams must independently assess their situation and decide which rating system is most applicable1. References: LEED v4: Building Design + Construction Guide, LEED Rating System Selection Guidance1

According to the LEED Reference Guide for Building Design and Construction1, the Integrative Process Prerequisite, Integrative Project Planning and Design, requires the project to assemble an integrated project team that includes at least four key project team members, in addition to the owner or owner’s representative. The key project team members are those who have the authority and responsibility to make design decisions and implement them during construction. The integrated project team should include professionals from different disciplines, such as architecture, engineering, landscape, interior design, construction, commissioning, operations, and maintenance. The integrated project team should collaborate throughout the project phases, from discovery to occupancy, to achieve the project goals and optimize the building performance.

For Location and Transportation (LT) Credit: High Priority Site, Option 1: Historic District, the project team must confirm that at least 75% of land areas within 1/2 mile (0.80 km) are previously developed (B). This demonstrates that the project site is part of an infill area, supporting LEED’s goal to revitalize and use previously developed urban spaces while protecting undeveloped land. Options like Federal Renewal Community status (C) or brownfield designation (D) apply to different site categories.

According to the LEED v4: Building Design + Construction Guide, the Location and Transportation Credit, Access to Quality Transit has two options: Option 1. Transit-Served Location and Option 2. Transit Service Quality. Option 1 can earn 1 to 4 points depending on the percentage of functional entries within walking distance of transit stops or stations. Option 2 can earn 1 point if the project meets the minimum weekday and weekend headways for bus, streetcar, or informal transit stops, or rail stations or ferry terminals. The maximum number of points a project can achieve under this credit is 4 points by meeting both options1. References: LEED v4: Building Design + Construction Guide, Location and Transportation Credit, Access to Quality Transit, Requirements1

The document that details ideas, concepts, and criteria that are essential for a building's success is the Owner's Project Requirements (OPR). The OPR outlines the goals, expectations, and criteria from the owner’s perspective, setting a foundational vision for the project. It is used in LEED AP ID+C certification as a guideline for aligning design and construction decisions with the owner's objectives. The Basis of Design (BOD) then takes the OPR’s high-level goals and translates them into technical requirements. Both documents support integrated project delivery by helping ensure design aligns with the owner's goals, but the OPR specifically details what the owner considers essential.

According to the LEED v4: Building Design + Construction Guide, the document that allows a LEED AP to register a project and sign the Certification Agreement is the Owner Confirmation of Agent Authority. This form is used to validate the Certification Agreement when it is signed by someone other than the owner, such as a LEED AP. It provides proof that the owner accepts the conditions in the Certification Agreement and authorizes the LEED AP to act as the owner’s agent for the purpose of LEED project certification1. The other choices are not relevant documents for this purpose. References: LEED Certification Agreement and other legal matters1

A charrette is a collaborative design process that involves multiple stakeholders, such as the owner, the design team, the community, and the users. By including the public in a charrette for a new school before the pre-design phase, potential partnerships with the community can be revealed. For example, the school might share facilities or resources with a nearby library, park, or community center. This can enhance the social and environmental benefits of the project, as well as reduce costs and increase efficiency. References: LEED BD+C Reference Guide, Introduction, page 171; LEED BD+C Reference Guide, Integrative Process, page 291

This building classification requires the energy model to determine the predicted power usage effectiveness (PUE) for Energy and Atmosphere Prerequisite, Minimum Energy Performance, because data centers have high energy intensity and cooling demand, and PUE is a metric that measures how efficiently a data center uses energy12.

The Commissioning Authority (CxA) plays a key role in ensuring building systems meet the Owner’s Project Requirements (OPR).

The CxA must review the OPR to confirm that design and construction decisions align with the owner's sustainability and performance goals.

The CxA should be independent and cannot be part of the project's design or construction management team if the project is larger than 20,000 sq. ft.

The CxA reports findings to the owner, not the architect.

While experience is required, LEED does not specify that only one project is needed for eligibility.

(Source: Official LEED BD+C Reference Manual)

This option requires the project team to focus on reducing the water consumption of the school project, because it is located in a basin that depends on the seasonal snowmelt for its water supply1. Installing efficient plumbing fixtures, such as low-flow faucets, toilets, and showerheads, can help save water and reduce the demand on the local water resources2. This option can also help the project achieve the LEED credits for outdoor and indoor water use reduction3.

An accessible garden with native plants supports:

Sustainable Sites (SS) Credit: Open Space by providing outdoor access and promoting biodiversity.

Sustainable Sites (SS) Credit: Rainwater Management by improving stormwater infiltration and reducing runoff.

Other options are not directly related to native gardens.

(Source: Official LEED BD+C Reference Manual)

The current facilities requirements (CFR) and operations and maintenance plan (OMP) are two documents that are required for the Energy and Atmosphere Prerequisite, Fundamental Commissioning and Verification. The CFR is a document that describes the owner’s project requirements, such as the design intent, performance goals, and operational needs of the building. The OMP is a document that provides information and guidance on how to operate and maintain the commissioned systems and equipment. According to the LEED v4 Reference Guide for Building Design and Construction, the CFR and OMP must include the minimum outside air requirements, which are the minimum rates of outdoor air ventilation that are needed to provide acceptable indoor air quality and thermal comfort for the occupants1. The issue logs, functional performance tests, and installation verification (construction) checklists are not required to be included in the CFR and OMP, but they are part of the commissioning process and documentation.

Average number of occupants standing or seated

To identify the regularly occupied spaces on a project, the LEED consultant should consider the average number of occupants standing or seated in each space, as this is the criterion used by the LEED Reference Guide for Green Building Design and Construction, 20091. Regularly occupied spaces are defined as areas where workers are seated or standing as they work (or perform regular tasks) inside a building2. The typical duration of occupancy in each space per day is not necessarily relevant, as some spaces may be used intermittently but still qualify as regularly occupied2. The rate of outdoor air provided per person and the fire ratings of installed wall and ceiling assemblies are not related to the definition of regularly occupied spaces, but rather to other credits such as Indoor Environmental Quality or Fire and Life Safety.

According to the LEED minimum program requirements, the LEED project must include a minimum of 1000 square feet (93 square meters) of gross floor area for the LEED BD+C and LEED O+M rating systems1.

In LEED-certified projects, residential buildings (D) are the exception to the rule prohibiting smoking inside buildings. For residential projects, the standard is modified to require designated smoking areas with special ventilation or separation rather than a complete ban, as smoking regulations in residential settings often involve tenant rights and are treated differently than commercial or institutional buildings. LEED requires that precautions be taken to control environmental tobacco smoke migration in multifamily residential projects to protect air quality in common areas.

Coordinating open space features early during the site planning phase is a viable strategy for optimizing open space under Sustainable Sites Credit, Open Space. This can help to preserve natural habitats, reduce heat island effects, and enhance human health and well-being. The credit requires that the project provide outdoor space that is at least 30% of the total site area, and that at least 25% of that outdoor space meets certain criteria for vegetated, pervious, or shaded areas. References:

LEED credit library: This is the USGBC’s comprehensive listing of all the LEED credits available in pursuing certification for your project. The credit library contains the requirements and guidance for each credit, as well as the web-based reference guide for the Building Design and Construction rating system.

Open Space: This is the specific credit page for the Open Space credit under the Sustainable Sites category. It provides the intent, requirements, and strategies for achieving the credit, as well as the number of points available and the applicable project types.

Step by Step Approach to Comply with the Open Space Credit in LEED v4: This is a blog post that explains the steps and calculations involved in complying with the Open Space credit. It also provides some examples and tips for optimizing open space design.

Under LEED BD+C Sustainable Sites (SS) Credit: Joint Use of Facilities, Option 1, a project can earn points by making certain building spaces available to the general public.

Spaces must be accessible outside of school hours for community use.

Auditoriums, gymnasiums, and meeting rooms are commonly shared spaces that support community engagement.

Locker rooms (Option A) and health clinics (Option C) may be restricted to specific users.

The principal's office (Option B) is a private administrative space, not suitable for public use.

An auditorium qualifies as a shared-use space that aligns with LEED requirements.

(Source: Official LEED BD+C Reference Manual)

The make and model of fixtures is required in determining the baseline for the Water Efficiency Prerequisite, Indoor Water Use Reduction. This information is used to calculate the baseline water consumption of the building, which is then compared to the proposed water use to determine the percentage reduction.

A preventive maintenance plan is a document that outlines the procedures and schedules for maintaining the building systems and equipment. It helps to ensure that the systems and equipment are operating efficiently and effectively, and that they meet the design intent and performance goals. A preventive maintenance plan can also help to reduce the risk of failures, breakdowns, and repairs, and extend the service life of the systems and equipment. A preventive maintenance plan is especially important for improving the indoor environmental quality, as it can prevent issues such as poor ventilation, air leaks, moisture problems, mold growth, and indoor air pollution. Therefore, the project team should provide the facility manager with a preventive maintenance plan for the building, along with the necessary training and resources to implement it.

Private lavatory faucets are eligible for a WaterSense label, provided they meet EPA’s specifications for water efficiency and performance, and are backed by independent, third-party certification. Tankless toilets, waterless urinals, and public lavatory faucets are not eligible for a WaterSense label because they are not included in the product categories that WaterSense covers. WaterSense currently labels products in the following categories: tank-type toilets, water-using urinals, private lavatory faucets, showerheads, irrigation controllers, spray sprinkler bodies, and pre-rinse spray valves. References:

WaterSense Products | US EPA1

The WaterSense Label | US EPA2

Water Sense Labeling | LEEDuser3

Labeled Faucet Questions | WaterSense | US EPA4

What is the WaterSense Label and How Does it Apply?5

To achieve the Sustainable Sites Credit, Light Pollution Reduction, Option 1. BUG Rating Method, projects must demonstrate that all luminaires meet acceptable fixture ratings for the project’s Model Lighting Ordnance (MLO) lighting zone. The MLO lighting zone is determined by the site-specific characteristics and the definitions provided in the IES/IDA MLO User Guide1. The fixture ratings are based on the backlight-uplight-glare (BUG) system, which measures the amount of light emitted in different directions by a luminaire, as defined in IES TM-15-11, Addendum A2. The maximum allowable ratings for each lighting zone are given in Table 1 of the credit language3. References: IES/IDA MLO User Guide; IES TM-15-11, Addendum A; Light pollution reduction

This option requires the project to increase the breathing zone outdoor airflow by at least 20% above the minimum rates required by ASHRAE 62.1-2010. Therefore, the minimum design zone outdoor airflow is 0.120 CFM/ft2 x 1.2 = 0.144 CFM/ft2.

A pedestrian-oriented paving or turf area with physical site elements that accommodate outdoor social activities is necessary to satisfy the requirement for the outdoor space to be physically accessible when calculating the Sustainable Sites Credit, Open Space. This is because the outdoor space must be designed to encourage regular use by occupants and visitors1. A garden space dedicated to industrial food production for use by local communities may not be accessible to the building occupants and visitors2. A garden space with only one vegetation type and species during the summer for visual interest does not meet the requirement of having two or more types of vegetation or overhead vegetated canopy1. A dark paving area with site elements to encourage parking near wetlands or naturally designed ponds is not considered as pedestrian-oriented hardscape and may have negative impacts on the natural environment3.

According to the LEED v4 Reference Guide for Building Design and Construction, the Carbon Dioxide Monitoring strategy requires CO2 monitors to be located in each densely occupied space, which is defined as a space with a design occupant density of 25 people or more per 1,000 square feet (93 square meters). This strategy is intended to provide feedback on ventilation system performance and indoor air quality12 References: 1: LEED v4 Reference Guide for Building Design and Construction, Indoor Environmental Quality Credit: Enhanced Indoor Air Quality Strategies, Option 2: Additional Enhanced IAQ Strategies, Strategy 3: Carbon Dioxide Monitoring, page 704. 2: LEED v4 Reference Guide for Building Design and Construction, Glossary, page 1019.

According to the Integrative Process Credit, Integrative Process, the goal-setting workshop should identify targeted LEED credits. This is because the goal-setting workshop is a meeting that involves the project owner and key project team members to establish the project’s sustainability goals, design objectives, and performance targets. One of the outcomes of the workshop is to identify the LEED credits that are relevant and achievable for the project, based on the project scope, budget, schedule, and site conditions. Therefore, option B is the correct answer. The other options are not the objectives of the goal-setting workshop. Potential project sites (option A) are usually determined before the goal-setting workshop, as they affect the project’s feasibility and design. Expected water demand (option C) and expected energy demand (option D) are not identified in the goal-setting workshop, but rather in the preliminary water budget and the preliminary energy modeling, which are part of the analysis phase that follows the goal-setting workshop. For more information on the Integrative Process Credit, Integrative Process, you can refer to the LEED v4 Reference Guide for Building Design and Construction1 or the Projectific blog post on LEED Integrative Process Credit Explained2.

According to the LEED AP Building Design + Construction (LEED AP BD+C) V4 resources, the Water Efficiency Prerequisite for Indoor Water Use Reduction requires the project to reduce aggregate water consumption by 20% from the baseline. Therefore, the project can meet this prerequisite with a 24% water reduction. However, to earn points under the Water Efficiency Credit for Indoor Water Use Reduction, the project needs to achieve a higher level of water reduction, ranging from 25% to 50%. The credit awards points based on the percentage of water reduction achieved, as shown in Table 1. Thus, the project may pursue this credit if it can further reduce its water consumption by installing more efficient fixtures and fittings, appliances, equipment and processes.

Rainwater collected from the building roof would be the most appropriate nonpotable water source for use in a cooling tower. This is because rainwater is generally cleaner than other nonpotable sources and does not require extensive treatment before use. Additionally, using rainwater can help to reduce stormwater runoff, providing an additional environmental benefit.

 According to the LEED Reference Guide for Building Design and Construction1, the Indoor Environmental Quality Credit, Indoor Air Quality Assessment, Option 1. Flush-Out requires the project to perform a building flush-out by supplying a total air volume of 14,000 cubic feet of outdoor air per square foot of gross floor area while maintaining an internal temperature of at least 60°F and no higher than 80°F and relative humidity no higher than 60%. The gross floor area of the building is 1,000 ft2 and the ceiling height is 10 ft, so the required volume of supply air for the entire building flush-out is:

14,000 ft3/sf x 1,000 sf = 14,000,000 ft3

The correct answer is D, provide qualifying electrical vehicle supply equipment in 2% of all parking spaces. According to the LEED v4 Reference Guide for Building Design and Construction, the Location and Transportation Credit, Green Vehicles, requires that projects provide preferred parking for green vehicles for 5% of the total vehicle parking capacity of the site. Green vehicles are defined as vehicles that achieve a minimum green score of 40 on the American Council for an Energy Efficient Economy (ACEEE) annual vehicle rating guide1 In addition, projects must provide one of the following:

Install alternative-fuel fueling stations for 3% of the total vehicle parking capacity of the site. Alternative fuels are defined by the U.S. Energy Policy Act of 1992 and include biodiesel, electricity, ethanol, hydrogen, natural gas, and propane.

Install electrical vehicle supply equipment (EVSE) for 2% of the total vehicle parking capacity of the site. EVSE must be Level 2 or higher as defined by SAE International’s J1772 standard.

Provide a discounted parking rate of at least 20% for green vehicles. The discounted rate must be available to all customers (not limited by time of day or user groups), publicly posted at the entrance of the parking area, and included in all marketing materials for the parking facility1

In this case, the project team has provided preferred parking for green vehicles for 20% of the total vehicle parking capacity of the site (4 out of 20 spaces), which exceeds the minimum requirement of 5%. However, they still need to provide one of the additional options listed above to achieve the credit. The most feasible option for a school project with a small parking lot would be to install EVSE for 2% of all parking spaces, which would be equivalent to one space. Therefore, answer D is correct.

The other answers are incorrect because they do not meet the credit requirements. Answer A is incorrect because providing preferred parking alone is not sufficient to achieve the credit; one of the additional options must also be provided. Answer B is incorrect because providing bike racks is not relevant to this credit, which focuses on green vehicles; bike racks are part of another credit, Location and Transportation Credit, Bicycle Facilities. Answer C is incorrect because providing an additional parking space for a low-emitting and fuel-efficient vehicle would not increase the percentage of preferred parking above 20%, which is already more than enough; moreover, low-emitting and fuel-efficient vehicles are defined differently from green vehicles in LEED v4 and have their own credit, Location and Transportation Credit, Reduced Parking Footprint1 References: 1: LEED v4 Reference Guide for Building Design and Construction, Location and Transportation Credit: Green Vehicles, page 467.

Detailed Explanation:

A reduction of 30% in outdoor water use qualifies the project for one point under the Outdoor Water Use Reduction credit, and a 40% reduction in indoor water use qualifies for four points under the Indoor Water Use Reduction credit. LEED awards points for water conservation strategies that significantly reduce the demand for potable water.

The correct answer is B. Provide for at least 10% of all regular building occupants, with no less than five storage spaces per building.

According to the LEED v4.1 Bicycle Storage Requirements1, commercial projects must provide long-term bicycle storage for at least 10% of all regular building occupants, with no less than five storage spaces per building. Long-term bicycle storage is defined as secure, enclosed, and weather-protected spaces that are intended for use by occupants who make regular trips to the project building. Examples of long-term bicycle storage include lockers, cages, rooms, or dedicated areas within buildings1. The purpose of this requirement is to encourage the use of bicycles as a sustainable mode of transportation and reduce greenhouse gas emissions and fossil fuel consumption.

According to the LEED v4: Building Design and Construction Guide, an integrated, whole-building approach is a process that requires collaboration and communication among all project team members and stakeholders throughout all phases of a project, from pre-design to occupancy and operations. The goal of this approach is to optimize the environmental and human health performance of a building as a whole, rather than focusing on individual components or systems1.

One of the benefits of an integrated, whole-building approach is that it allows the project team to identify and evaluate the interrelationships and trade-offs among various design strategies and decisions, and to optimize the synergies and minimize the conflicts among them1. For example, increasing the size of a glazed opening on the south facing wall may have implications for the daylighting, solar heat gain, thermal comfort, energy use, and mechanical system design of the building2. Therefore, the team members who are first affected by this change are the mechanical engineers, who are responsible for designing the heating, ventilation, and air conditioning (HVAC) system of the building, and ensuring that it meets the thermal comfort and energy performance requirements of the project3. The mechanical engineers may need to adjust the size, type, and location of the HVAC equipment, ductwork, and controls, as well as perform energy modeling and analysis to evaluate the impact of the change on the building’s energy consumption and emissions3. The mechanical engineers may also need to coordinate with the architects, lighting designers, and other team members to ensure that the change does not compromise the other design goals and criteria of the project3.

The referenced standard for Indoor Environmental Quality (IEQ) Prerequisite: Minimum Indoor Air Quality (IAQ) Performance in LEED AP ID+C projects is ASHRAE 62.1 - 2010. ASHRAE 62.1 specifies ventilation rates and air quality requirements for acceptable indoor air quality in commercial buildings, establishing the minimum standards needed to maintain health and comfort. ASHRAE 62.2 (A) is relevant to low-rise residential buildings, ASHRAE 90.1 (B) covers energy standards, and ASHRAE 55 (C) relates to thermal comfort rather than air quality.

To comply with Indoor Environmental Quality Credit, Thermal Comfort, the standard that needs to be followed is ASHRAE 55-2010, Thermal Environmental Conditions for Human Occupancy, with errata or a local equivalent1. This standard specifies the combinations of indoor thermal environmental factors and personal factors that will produce thermal environmental conditions acceptable to a majority of the occupants within the space2. The standard also provides methods for measuring and evaluating thermal comfort, as well as guidance for design, operation, and maintenance of thermal comfort systems2. References: Thermal comfort; ASHRAE 55-2010

Detailed Explanation:

To meet the requirements for EVSE compliance under LEED, the equipment must adhere to regional, state, or local standards for electrical connectors. This ensures alignment with the local codes and practices for electric vehicle infrastructure, supporting accessibility and usability of EVSE. LEED prioritizes sustainable transportation by promoting infrastructure that meets standardized requirements, enabling efficient and effective EV charging.

The LEED Accredited Professional (LEED AP) plays a consultative role in helping the owner develop the Owner’s Project Requirements (OPR).

The OPR defines project goals, including energy efficiency, sustainability, and occupant comfort.

It is the owner’s responsibility to define the OPR, while the LEED AP provides guidance and technical expertise.

The design team and commissioning authority (CxA) reference the OPR throughout the project.

A LEED AP does not author, oversee, or publish the document, but ensures that LEED goals align with the project’s sustainability vision.

(Source: Official LEED BD+C Reference Manual)

In determining the LEED project boundaries, the LEED AP may include non-contiguous parcels of land if the parcels directly support or are associated with normal building operations and are accessible to the project’s occupants. This is according to the Minimum Program Requirements (MPRs) for LEED v4.1, which state that non-contiguous parcels of land may be included within the LEED project boundary if they meet these criteria1. Facilities such as parking lots, bicycle storage, shower/changing facilities, and/or on-site renewable energy that are outside of the LEED project boundary may also be included in certain prerequisites and credits if they directly serve the LEED project and are not double-counted for other LEED projects1. The other options are not valid reasons to include non-contiguous parcels of land within the LEED project boundary. Temporary uses such as parking or staging that are owned and managed by a third party do not directly support or are associated with normal building operations of the LEED project1. Existing public preservation easements or resource protection areas that are directly adjacent to the LEED project boundary are not considered as part of the LEED project boundary, unless they are owned by the project owner or the project team has permission to use them2. Land trusts or conservation organizations for which the LEED project provides financial support are not considered as part of the LEED project boundary, unless they are located within the same EPA Level III ecoregion as the project site3.

Natural daylighting can reduce the electricity use for artificial lighting, which is one of the major components of operational energy cost for buildings. By having the lights off or dimmed when sufficient daylight is available, the project can save energy and money. The other options are not necessarily true or relevant for natural daylighting. Heat gain and passive solar heating depend on the orientation, shading, and insulation of the windows, not just the amount of daylight. Reduction in lighting fixture use may reduce re-lamping, but that is not a significant factor in operational energy cost compared to electricity use. References: EA Credit Optimize Energy Performance, EQ Credit Daylight, LEED v4 Reference Guide for Building Design and Construction123

For Energy and Atmosphere (EA) Credit: Advanced Energy Metering, any individual energy end uses that represent 10% or more of the total annual energy consumption must be metered (A). This credit promotes ongoing energy management and helps identify large energy-consuming systems for efficiency improvements. Metering data from major end uses can provide insights into energy patterns, facilitating targeted actions to reduce consumption.

The Materials and Resources Credit, Building Product Disclosure and Optimization - Sourcing of Raw Materials rewards projects that use materials that have optimized extraction processes by limiting or eliminating the extraction of new resources, the reuse of materials or the use of recycled materials1. According to the LEED Reference Guide for Building Design and Construction2, the credit has two options: Option 1. Raw Material Source and Extraction Reporting and Option 2. Leadership Extraction Practices. Option 1 requires the project to use at least 20 permanently installed products from at least five different manufacturers that have publicly released a report from their raw material suppliers which include extraction locations, a commitment to long-term ecologically responsible land use, a commitment to reducing environmental harms from extraction and/or manufacturing processes, and a commitment to meeting applicable standards or programs voluntarily that address responsible sourcing criteria2. Option 2 requires the project to use products that meet at least one of the responsible sourcing criteria below for at least 25%, by cost, of the total value of permanently installed building products in the project:

Extended producer responsibility. Products purchased from a manufacturer (producer) that participates in an extended producer responsibility program or is directly responsible for extended producer responsibility.

Bio-based materials. Bio-based products must meet the Sustainable Agriculture Network’s Sustainable Agriculture Standard. Bio-based raw materials must be tested using ASTM Test Method D6866 and be legally harvested, as defined by the exporting and receiving country. Exclude hide products, such as leather and other animal skin material.

Wood products. Wood products must be certified by the Forest Stewardship Council or USGBC-approved equivalent.

Materials reuse. Reused products must include salvaged, refurbished, or reused products.

Recycled content. Recycled content is the sum of postconsumer recycled content plus one-half the preconsumer recycled content, based on cost. Products meeting recycled content criteria are valued at 100% of their cost for the purposes of credit achievement calculation.

USGBC approved program. Other USGBC approved programs meeting leadership extraction criteria.

Therefore, among the given options, only Option A is relevant to the use of reused/salvaged materials or recycled content, as they can contribute to the materials reuse or recycled content criteria under Option 2. Option B is a prerequisite that requires the project to develop and implement a construction and demolition waste management plan that identifies the materials to be diverted from disposal and whether the materials will be sorted on-site or co-mingled2. Option C is a credit that requires the project to use at least 20 different permanently installed products from at least five different manufacturers that use any of the following programs to demonstrate the chemical inventory of the product to at least 0.1% (1000 ppm):

Health Product Declaration. The end use product has a published, complete Health Product Declaration with full disclosure of known hazards in compliance with the Health Product Declaration Open Standard.

Cradle to Cradle. The end use product has been certified at the Cradle to Cradle v2 Basic level or Cradle to Cradle v3 Bronze level.

REACH Optimization. The end use product is compliant with REACH Optimization criteria.

GreenScreen v1.2 Benchmark. The product’s chemical ingredients are inventoried using the GreenScreen v1.2 Benchmark.

Declare. The Declare product label must indicate that all ingredients have been disclosed down to 1000 ppm.

Option D is a credit that requires the project to use at least 20 different permanently installed products that have environmental product declarations. The products must be sourced from at least five different manufacturers. The environmental product declarations must conform to ISO 14025, 14040, 14044, and EN 15804 or ISO 21930 and have at least a cradle-to-gate scope2.

Discovery

The discovery phase of the integrative process gives the team the greatest chance of success in meeting the project’s environmental goals cost-effectively. The discovery phase is the initial stage of the project, where the team establishes the vision, goals, and performance criteria, conducts a site assessment, identifies synergies and trade-offs among systems, and performs preliminary analysis and modeling of energy and water use1. By engaging in this phase early and iteratively, the team can explore various design options, identify potential savings and benefits, and optimize the project outcomes2.

The Materials and Resources Credit, Construction and Demolition Waste Management aims to reduce the amount of construction and demolition waste disposed of in landfills and incineration facilities by recovering, reusing, and recycling materials. According to the LEED v4 Reference Guide for Building Design and Construction, one of the options to achieve this credit is to divert at least 50% of the total construction and demolition material from disposal and recycle or salvage at least three material streams1. Therefore, salvaging and recycling 50% of the existing materials (based on volume) generated during site demolition for three material streams would contribute to earning this credit. The other options are not related to this credit, but to other credits or prerequisites, such as Sustainable Sites Prerequisite: Construction Activity Pollution Prevention1, Materials and Resources Prerequisite: Storage and Collection of Recyclables1, and Materials and Resources Credit: Building Product Disclosure and Optimization - Sourcing of Raw Materials1.

When calculating the reverberation time of a room, the operating sound level of the nearest HVAC equipment is the least relevant piece of information. The reverberation time is the time it takes for the sound to decay by 60 decibels after the source stops emitting sound. The reverberation time depends on the volume and the surface area of the room, as well as the sound absorption coefficients of the materials that cover the surfaces. The height and width of the room are needed to calculate the volume and the surface area. The noise reduction coefficient of the ceiling surface and the sound absorption coefficient of the floor surface are needed to calculate the total sound absorption of the room. The operating sound level of the nearest HVAC equipment is not relevant for calculating the reverberation time, but it may affect the background noise level and the speech intelligibility in the room.

Source reduction focuses on minimizing waste at its origin.

Prefabrication reduces waste by manufacturing components off-site with optimized material use, leading to less on-site cutting, packaging waste, and construction debris.

Custom design (Option A) and design-build (Option B) do not inherently reduce waste.

Material science (Option C) refers to material properties but does not directly address waste reduction.

Prefabrication is the most effective source reduction strategy, making Option D correct.

(Source: Official LEED BD+C Reference Manual)

The Owner’s Project Requirements (OPR) is a document that defines the goals, expectations, and performance criteria of the project, as established by the owner or the owner’s representative1. The OPR is one of the key deliverables of the commissioning process and serves as the basis for the design, construction, and operation of the building systems. Therefore, the priority for the Commissioning Authority (CxA) to consider when the contractor substitutes a higher efficiency piece of equipment is whether the substitution meets or exceeds the OPR. The CxA should verify that the new equipment is compatible with the OPR and does not compromise the performance, functionality, or reliability of the system. The CxA should also communicate the substitution to the owner and the design team and document the change in the commissioning plan and report.

LEED Building Design and Construction: Healthcare has additional appliance and process water requirements in Water Efficiency Prerequisite, Indoor Water Use Reduction

LEED Building Design and Construction: New Construction and LEED Building Design and Construction: Healthcare have the same Water Efficiency credits, except for the Cooling Tower Water Use credit, which is only applicable to the former. However, the Indoor Water Use Reduction prerequisite differs between the two rating systems, as the Healthcare version requires additional calculations for appliance and process water use, such as medical equipment, laundry, and kitchen equipment.

An intensive vegetated roof is a roof that has a thick layer of soil and plants that provide shade, evapotranspiration, and stormwater management. It can reduce the heat island effect by lowering the surface and air temperature of the roof and the surrounding area. Artificial turf grass does not reduce the heat island effect because it is not a living plant and does not provide cooling benefits. A steep sloped roof with initial SRI of 35 does not meet the minimum requirement of 39 for Option 1 or 32 for Option 2 of the Heat Island Reduction credit. A low sloped roof with initial SRI of 64 exceeds the minimum requirement of 82 for Option 1 or 64 for Option 2, but it is not the best option among the choices because it only reflects solar radiation and does not provide other benefits such as shading, evapotranspiration, and stormwater management. References:

Heat Island Reduction credit in LEED BD+C: New Construction v4.1 - LEED v4.11

SpecTopics: Heat Island Reduction Credit and LEED® V4/V4.12

LEED Principle: Urban Heat Island Mitigation and Roofing3

The most likely group of documents to support both Indoor Environmental Quality Credit, Thermal Comfort, and Indoor Environmental Quality Credit, Interior Lighting, Option 1. Lighting Control is C, lighting plans, surveys of occupants, sequence of operations.

Lighting plans show the layout and type of lighting fixtures, as well as the lighting controls, such as dimmers, timers, occupancy sensors, or daylight sensors. Surveys of occupants provide feedback on the satisfaction and comfort level of the building users regarding the thermal and lighting conditions. Sequence of operations describes how the mechanical and lighting systems operate and respond to different scenarios, such as occupancy, temperature, or daylight levels.

These documents can demonstrate that the project meets the requirements for both credits, which are:

For Thermal Comfort, the project must design the HVAC systems and the building envelope to meet the requirements of ASHRAE Standard 55-2010, Thermal Environmental Conditions for Human Occupancy, or a local equivalent, and provide individual thermal comfort controls for at least 50% of the individual occupant spaces, and group thermal comfort controls for all shared multi-occupant spaces1.

For Interior Lighting, Option 1. Lighting Control, the project must provide individual lighting controls that enable adjustments to suit individual task needs for at least 90% of the individual occupant spaces, and provide lighting system controls for all shared multi-occupant spaces that allow occupants to adjust the lighting to meet group needs and preferences2.

The other groups of documents are less likely to support both credits, because:

Architectural floor plans, mechanical plans, and lamp specifications do not show the lighting controls or the occupant feedback.

Photometric plans, mechanical schedules, and lamp specifications do not show the thermal comfort design or the occupant feedback.

Surveys of occupants, photometric plans, and mechanical schedules do not show the lighting controls or the thermal comfort design.

The credit may be achieved by using nonroof measures only, such as shading, paving, and vegetation, to reduce the heat island effect on the site. The credit does not require a highly reflective roof for all projects, but allows for flexibility and trade-offs depending on the climate and design conditions. The project can use the Heat Island Reduction 1 to demonstrate compliance with the credit requirements. The credit is feasible and applicable for this project, and does not need an alternative compliance path. References: SS Credit Heat Island Reduction, LEED v4 Reference Guide for Building Design and Construction234

A benefit of earning Regional Priority credits is that the LEED project can achieve more sustainable outcomes by recognizing the issues that are a priority in the project’s location. Regional Priority credits are not new LEED credits, but instead are existing credits that USGBC regional councils and chapters have designated as being particularly important for their areas1. The incentive to achieve the credits is in the form of a bonus point. If an RP base credit is earned, then a bonus point is awarded to the project’s total points1. This way, the project can address the geographically specific environmental, social equity and public health priorities of its location2. References:

Regional priority credit lookup | U.S. Green Building Council

Regional Priority (RP) credits – U.S. Green Building Council

The Location and Transportation Credit, Bicycle Facilities, requires the project team to provide a vicinity map that shows the bicycle network, the route and the distance along the network to eligible destination(s) for all LEED Building Design and Construction projects. The vicinity map is a supporting material that demonstrates that the project site is within a 200-yard (180-meter) walking distance of a bicycle network that connects to at least one of the following: diverse uses, public transportation, recreation facilities, or schools1. The vicinity map must also show the scale and the north arrow, and indicate the project site and the eligible destination(s)2. The photographs of bicycle network signage and directional signposts, the photographs of the installed bicycle storage and shower facilities, and the manufacturer specifications for the chosen bicycle storage facilities are not required for the bicycle network, but for the bicycle storage and shower facilities.

For Energy and Atmosphere Credit, Advanced Energy Metering, the minimum amount of time that the metering system should store data is 36 months. This is to ensure that the data can be used for long-term analysis and verification of energy performance1. The credit also requires that the metering system be capable of transmitting data to a remote location and reporting energy use at least hourly1. References: Advanced energy metering

The first step in earning the Water Efficiency (WE) Credit: Cooling Tower Water Use is to identify the maximum number of cycles of concentration for the cooling tower or evaporative condenser. This step establishes a baseline for water quality and helps determine potential water savings through maximizing the number of cycles, which minimizes water and chemical usage in cooling systems. Subsequent steps may involve chemical analysis (D) or exploring alternative water sources, but setting the cycles is the initial requirement.

The best design approach for the office building is D. Recover waste energy through exhaust air energy recovery systems. This is because:

Installing glazing with a higher solar heat gain factor would increase the cooling load and energy consumption of the building, especially in an extremely humid climate where heat gain is high1.

Installing photovoltaic panels on the sides of the building would generate electricity from solar radiation, but it would not reduce the cooling load or energy consumption of the building, unless the electricity is used to power a heat pump or other cooling device2.

Increasing outdoor air intake quantities during summer months would provide more fresh air to dilute the indoor pollutants and improve the indoor air quality, but it would not reduce the cooling load or energy consumption of the building, unless it is combined with a ventilation system that recovers waste energy from the exhaust air stream34.

An exhaust air energy recovery system (ERV) is a type of mechanical ventilation that uses a heat exchanger to transfer heat between two streams of air: one that enters the building and one that exits. The ERV pre-cools and dehumidifies the incoming ventilation air by sending the rejected heat into the exhaust airstream to cool the condenser coil at a lower temperature. This reduces both the cooling load and energy consumption of the building, as well as improving its indoor humidity levels34. An ERV can also provide some fresh outdoor air to meet ASHRAE Standard 62 ventilation rates5.

Therefore, an ERV is a more efficient and effective design approach than glazing, photovoltaic panels, or increased outdoor air intake quantities for reducing the annual energy cost for operating an office building in an extremely humid climate and shaded by very large adjacent buildings on all four sides.

For the Materials and Resources Credit, Building Life-Cycle Impact Reduction, Option 2. Renovation of Abandoned or Blighted Buildings, up to 25% of the building surface area may be excluded from the credit calculation due to deterioration or damage1.

The basis of energy consumption in determining the percentage of green power or carbon offsets is the quantity of energy used by the project, measured in kilowatt-hours (kWh) or British thermal units (Btu). Green power is electricity generated from renewable sources, such as solar, wind, hydro, biomass, or geothermal. Carbon offsets are reductions or removals of greenhouse gas emissions from a project or activity that compensates for the emissions from another source. According to the LEED Reference Guide for Building Design and Construction1, the Energy and Atmosphere Credit, Green Power and Carbon Offsets, requires the project to engage in a contract for qualified resources that meet the following requirements:

The contract term is at least five years.

The green power or carbon offsets are based on the quantity of energy consumed by the building.

The green power is Green-e Energy certified or the equivalent.

The carbon offsets are Green-e Climate certified, Verified Carbon Standard certified, Gold Standard certified, or the equivalent.

Makeup water meters, conductivity controllers and overflow alarms

According to the Water Efficiency Prerequisite for Indoor Water Use Reduction, cooling towers and evaporative condensers must be equipped with makeup water meters, conductivity controllers and overflow alarms to reduce water consumption and prevent water waste. These devices help monitor and control the water quality, flow rate and level of the cooling system, and alert the operators of any malfunctions or leaks.

Exemplary performance credits are one of the options to earn innovation points under the LEED v4.1 rating system. They are typically awarded for achieving double the credit requirements or the next incremental percentage threshold of an existing LEED v4.1 prerequisite or credit that allows exemplary performance. For example, to earn an exemplary performance point for the Energy and Atmosphere credit Optimize Energy Performance, the project must demonstrate a percentage improvement in the proposed building performance rating compared to the baseline building performance rating per ASHRAE 90.1-2010 by at least 12 percentage points for new construction, or by at least 16 percentage points for major renovations.

Pilot Credit registration is required when documenting a LEED Pilot credit. This is to ensure that the project team has access to the latest pilot credit language and requirements, and that USGBC can track the usage and feedback of the pilot credits. The other options are not required for documenting a pilot credit, although they may be helpful or applicable for other credits.

A simple box energy analysis, also known as a "mass model" analysis, is performed during the early design phases, typically before the completion of the schematic design. This assessment involves creating a simplified model of the proposed building to evaluate its potential energy performance. The goal is to explore various design options and strategies that can reduce energy consumption, such as building orientation, envelope characteristics, and massing. Conducting this analysis early allows the design team to make informed decisions that enhance energy efficiency from the outset. ​

To evaluate the Location and Transportation (LT) Credit: Reduced Parking Footprint, the project team should be aware of the minimum number of parking spaces required by the zoning code (D). This credit aims to reduce the environmental impact of parking by minimizing the number of spaces provided, encouraging alternative transportation methods. Knowledge of local parking minimums helps the team ensure compliance with LEED while avoiding excess parking, which can contribute to urban sprawl and the heat island effect. Design guidelines and building code standards are not directly relevant to this credit.

This credit can be earned if the VOC budget method is applied for VOC content. The VOC budget method allows the use of some products that exceed the VOC content limit, as long as the total VOC content of all products within a category does not exceed the total allowable VOC content for that category1. The adhesive is a product within the wet-applied and aerosol adhesives category, which has a VOC content limit of 70 g/L1. The contractor must calculate the VOC budget for this category and ensure that it does not exceed the limit. The other options are not valid ways to earn this credit. The adhesive must be included in the LEED documentation, as all products used in the project must be accounted for1. The credit requires that 100% of the adhesives used comply with the VOC content limit and emissions requirements, not 75% or 95%1.

Detailed Explanation:

Cradle-to-cradle certification (Gold level) meets the requirements for Material Ingredient Optimization under Option 2. It demonstrates the product’s compliance with advanced environmental standards, supporting the LEED focus on transparency and optimization of building materials to minimize their environmental and human health impacts.

According to the LEED v4 Reference Guide for Building Design and Construction, the project must provide outdoor space that is at least 30% of the total site area (including the building footprint), of which at least 25% must be vegetated. In this case, the project must provide 0.3 x 240,000 ft2 = 72,000 ft2 (6 689 m2) of outdoor space, of which 0.25 x 72,000 ft2 = 18,000 ft2 (1 672 m2) must be vegetated. Therefore, option C is the correct answer. References: LEED v4 Reference Guide for Building Design and Construction, p. 5411

According to the LEED v4: Building Design + Construction Guide, the Sustainable Sites Credit, Open Space requires the project to provide outdoor space greater than or equal to 30% of the total site area (including building footprint). At least 25% of that outdoor space must be vegetated, have overhead vegetated canopy, or be a water body. Option A does not qualify as outdoor space, Option B is not vegetated or a water body, and Option C only applies to projects with a FAR of less than 1.0. Option D meets the requirements for both outdoor space and vegetation, and also contributes to the protection or restoration of habitat1. References: LEED v4: Building Design + Construction Guide, Sustainable Sites Credit, Open Space, Requirements1

Detailed Explanation:

The LEED boundary for Phase 1 can include only the building site (Phase 1) but must commit to keeping the Phase 2 grounds undisturbed until the second phase begins. This approach aligns with LEED's requirement to define boundaries where work occurs and ensures environmental protection for future development areas.
