Supporting Cisco Datacenter Networking Devices Questions and Answers

Question 1

Which two blade servers support GPUs? (Choose two.)

Options:

A.

UCS B260 M4

B.

UCS B200 M4

C.

UCS B420 M4

D.

UCS B480 M5

E.

UCS B200 M5

Question 2

Which two statements about Cisco UCS S3260 Storage Server are true? (Choose two.)

Options:

A.

AMD EPYC 7000 series processors, with up to 32 cores per socket

B.

Up to 1 TB of Intel Optane DC Persistent Memory

C.

It is in a compact 2-RU form factor.

D.

Support for the Cisco 12-G 9460-8i PCle SAS RAID controller

E.

Massive 840-TB data storage capacity

Question 3

Which two statements are true for the Ethernet 802.3 standard? (Choose two.)

Options:

A.

An 802.3 Ethernet frame is 68 to 1518 bytes in length.

B.

CSMA/CD eliminates collisions for the switched LAN where multiple collision domains reside.

C.

It defines physical layer and data link layer protocols.

D.

The IEEE 802.3ab standard defines 10 Gigabit Ethernet over unshielded twisted-pair (UTP).

E.

Network layer protocol is carried in the payload field.

Question 4

Question # 4

Refer to the exhibit. What is the cause for the System Status LED (item 7) to be a blinking red status?

Options:

A.

major fault with the system board

B.

secure boot validation has failed

C.

major fault with memory DIMM

D.

power on Self-Test (POST) failed

Question 5

Question # 5

Refer to the exhibit. Match the Fault Icons to the appropriate description.

Question # 5

Options:

Question 6

Which two Cisco Nexus switches provide the foundation of the Cisco Application Centric Infrastructure? (Choose two.)

Options:

A.

Cisco Nexus 7718 switch

B.

Cisco Nexus 9508 switch

C.

Cisco Nexus 7710 switch

D.

Cisco Nexus 93128TX switch

E.

Cisco Nexus 6004 switch

Question 7

Which three firmware components does the Host Upgrade Utility upgrade? (Choose three.)

Options:

A.

Fabric Interconnect firmware

B.

LAN on Motherboard

C.

Cisco UCS Manager

D.

CIMC

E.

System BIOS

Question 8

What are two common steps to troubleshooting a rack server with unrecognized or memory errors? (Choose two.)

Options:

A.

Ensure DIMMs are installed in correct slots

B.

Check CPU sockets for bent pins

C.

Check that the AC power cord is OK

D.

Reseat DIMMs

E.

Check the front I/O cable connection to the motherboard

Question 9

What are two descriptions for PCle? (Choose two.)

Options:

A.

The PCle 4.0 standard doubles the transfer rate compared to PCle 5.0.

B.

The PCle supports native hot-swap functionality.

C.

A link that is composed of four lanes is called an x4 link.

D.

The PCle standard is a bus-based system in which all the devices share the same bidirectional, 32-bit or 64-bit, parallel signal path.

E.

A PCI Express x16 adapter can be installed into an x4 slot.

Question 10

Refer to the exhibit.

Question # 10

Which item does D represent?

Options:

A.

Pin icon (prevents Navigation pane from sliding)

B.

Favorite icon (make any specific work pane in the application as your favorite)

C.

To view the Navigation pane

D.

Index Icon (view listing in alphabetical order)

Question 11

In the Cisco UCS S3260 Storage Server which two of the below ports are available on a System I/O Controller? (Choose two.)

Options:

A.

Dedicated Management port

B.

PCle ports

C.

KVM Console port

D.

QSFP port

E.

Ethernet LOM port

Question 12

Refer to the exhibit.

Question # 12

Which call-out accurately shows the current running version of the Cisco UCS Manager management software?

Options:

A.

A - UCS Manager running version 1.4(1m)

B.

B - IO Module 1 running version 1.4(1m)

C.

C - Interface Card 1 running version 1.4(1m)

D.

D - Kernel running version 4.2(1)N(1.4m)

Question 13

Which fiber optic cable type is used most often with a Subscriber connector?

Options:

A.

dual-mode

B.

single-mode

C.

straight-mode

D.

multi-mode

E.

subscriber-mode

Question 14

Which two UCS devices provide connectivity to Fabric Extenders? (Choose two.)

Options:

A.

UCS 6400 Series

B.

UCS 6300 Series

C.

UCS E-Series Servers

D.

UCS S-Series Storage Servers

E.

UCS B-Series Servers

Question 15

A company wants to build a data center infrastructure which can provide up to 99.982% uptime availability per year. Which ANSI/TIA-942 data center tier meets the requirement?

Options:

A.

Redundant-distribution site infrastructure

B.

Redundant-capacity component site infrastructure

C.

Concurrently maintainable site infrastructure

D.

Basic site infrastructure

Question 16

Which method does FCIP use to enable connectivity of geographically distributed Fibre Channel SANs over IP?

Options:

A.

routing

B.

tunneling

C.

handshaking

D.

transporting

Question 17

Which statement is true about cloud deployment models?

Options:

A.

A public cloud is typically infrastructure used by a single organization.

B.

Public clouds are more expensive than private clouds.

C.

Hybrid cloud supports multiple organizations sharing computing resources that are part of a community.

D.

Public clouds are less secure than private clouds.

Question 18

Which two form factors are available in the Cisco UCS E-Series Servers? (Choose two.)

Options:

A.

EHWIC

B.

PVDM

C.

NIM

D.

VIC

E.

WIC

Question 19

Refer to the exhibit.

Question # 19

Which item list all available functions that can be perform to the server?

Options:

A.

A

B.

B

C.

C

D.

D

Question 20

Which three troubleshooting procedures do you perform when there is no power to a Cisco UCS B250 M2 Blade Server? (Choose three.)

Options:

A.

Decommission and acknowledge the blade.

B.

Check the back of the blade to ensure that there is no damage to the connection that goes into chassis.

C.

Reseat the memory DIMMs.

D.

Check the CPU sockets for bent pins.

E.

Reseat the blade in the same slot in the chassis.

F.

Move the blade to another slot in the chassis.

Question 21

What do the small form-factor, x86 64-bit blade servers reside in Cisco branch-office router?

Options:

A.

Cisco UCS E-Series Servers

B.

Cisco UCS S-Series Storage Servers

C.

Cisco UCS Blade Servers

D.

Cisco UCS C-Series Rack-Mount Servers

Question 22

Which two statements about PCIe are true? (Choose two.)

Options:

A.

The PCle supports native hot-swap functionality.

B.

You can install a PCI Express x16 adapter into an x4 slot.

C.

The PCIe standard is a bus-based system in which all the devices share the same bidirectional, 32-bit or 64-bit, parallel signal path.

D.

The PCIe 4.0 standard doubles the transfer rate compared to PCIe 5.0.

E.

A link that is composed of four lanes is called an x4 link.

Question 23

Refer to the exhibit.

Question # 23

What is the name of this Cisco MDS 9700 Series network module?

Options:

A.

Cisco MDS 9700 48-port 16-Gbps switching module

B.

Cisco MDS 9700 48-port 32-Gbps Fibre Channel switching module

C.

Cisco MDS 48-Port 10-Gbps Fibre Channel over Ethernet module

D.

Cisco MDS 24-/10-port SAN Extension module

Question 24

Which two major components does a Cisco Nexus 1000V Series Switch have? (Choose two.)

Options:

A.

Virtual Fiber Channel Module

B.

Virtual Ethernet Module

C.

Virtual Supervisor Module

D.

Virtual Memory Controller Module

E.

Virtual Network Module

Question 25

Which statement about RAID is true?

Options:

A.

RAID is a scheme used to logically combine several independent disks to form an array or group of drives.

B.

RAID provides data redundancy with either odd parity or even parity.

C.

RAID drive group appears to the host computer as multiple physical storage units.

D.

RAID parity information can be stored across multiple RAID levels.

E.

RAID stores data in the array with data striping, encryption, and parity to organize the data among the disks.

Question 26

Which three statements about powering down a Cisco UCS C-Series Rack-Mount Server to perform maintenance or replacement are true? (Choose three.)

Options:

A.

Standby power mode: Power is supplied only to the service processor and the cooling fans, and it is safe to power off the server from this mode.

B.

Power status LED. Green indicates that the server is in main power mode and can be safely powered off.

C.

Graceful shutdown: Press and release the power button. The operating system performs a graceful shutdown, and the server goes to standby mode, which is indicated by an amber power status LED.

D.

Disconnect the power cords from the power supplies in your server to completely power off the server.

E.

Only an emergency shutdown can be performed using the power button on the server front panel.

F.

The Cisco UCS C-Series Rack-Mount Server has only one power mode.

Question 27

Which RAID level fault tolerance allows two disk failures?

Options:

A.

RAID 1

B.

RAID 4

C.

RAID 5

D.

RAID 6

Question 28

Which two statements about PCIe are true? (Choose two.)

Options:

A.

The PCIe link is built around dedicated unidirectional couples of serial, point-to-point connections known as lanes.

B.

You can install a PCI Express x8 adapter into an x4 slot.

C.

The PCIe standard is a bus-based system in which all the devices share the same bidirectional, 32-bit or 64-bit, parallel signal path.

D.

The PCIe 1.0 standard doubles the transfer rate compared to PCIe 2.0.

E.

A link that is composed of four lanes is called an x4 link.

Question 29

Which transceiver can support 400 Gigabit Ethernet?

Options:

A.

QSFP-DD

B.

QSFP+

C.

QSFP28

D.

SFP-DD

Question 30

What is a description of QSFP?

Options:

A.

100GBASE-SR4 supports a much longer distance than 100GBASE-LR4.

B.

The four 10 Gbit/sec channels that QSFP+ supports can be combined into a single 40 Gigabit Ethernet link.

C.

The QSFP+ offers higher data speed than QSFP28.

D.

QSFP-DD stands for Quad Small Form Factor Pluggable Double Distance.

Question 31

What are two functions of FCoE? (Choose two.)

Options:

A.

It allows Fibre Channel and Ethernet networks to share a single, integrated infrastructure.

B.

It consolidates I/O traffic in the data center.

C.

It allows Ethernet traffic to run over a Fibre Channel infrastructure.

D.

It increases capital costs due to the difficulty to manage.

E.

It encapsulates Ethernet frames into Fibre Channel frames, which allows them to run alongside traditional IP traffic.

Question 32

Refer to the exhibit.

Question # 32

Where is the best place to see the power supply status of the blade server enclosure?

Options:

A.

A - Chassis 1

B.

B - Chassis 1 - PSUs

C.

C - Chassis1 - Servers

D.

D - Rack-Mounts - Servers

E.

E - Fabric Interconnects A - PSUs

Question 33

Which Cisco UCS Virtual Interface Card Series is designed exclusively for the M5 generation?

Options:

A.

M81KR VIC

B.

VIC 1400 Series

C.

VIC 1300 Series

D.

VIC 1200 Series

Question 34

Which two statements about the Cisco Nexus 5596UP switch are true? (Choose two.)

Options:

A.

Its power supplies and fan trays are hot-swappable.

B.

It supports unified ports.

C.

It is offered in a one-rack-unit form factor.

D.

It has one expansion slot.

E.

It supports up to 96 10G BASE-T ports.

Question 35

Which three components are hot swappable in a Cisco UCS Blade Server and Chassis? (Choose three.)

Options:

A.

Fabric Extender

B.

Power supply

C.

Heat sink

D.

SAS Hard Drive

E.

2x8GB Kit DIMMs

F.

Mezzanine card

Question 36

Which two statements are true about system controllers of Cisco Nexus 9500 Series? (Choose two.)

Options:

A.

They provide centralized arbitration to the system fabric for all line cards.

B.

They control the Layer 2 and Layer 3 services.

C.

The Cisco Nexus 9500 Series switch software, Enhanced NX-OS, runs on the system controllers.

D.

They are used to offload the internal non-data-path switching and management functions from the supervisor engines.

E.

The Cisco Nexus 9500 Series supports redundant system controllers.

Question 37

Storage virtualization is commonly used for SANs in data centers to scale out the storage resources. The common methods of storage virtualization include array-based storage virtualization. What are the other two methods? (Choose two.)

Options:

A.

Host-based storage virtualization

B.

Hypervisor-based storage virtualization

C.

Embedded-based storage virtualization

D.

Switch-based storage virtualization

E.

Network-based storage virtualization

Question 38

What are two typical steps for troubleshooting a rack server with unrecognized or memory errors? (Choose two.)

Options:

A.

Check that the AC power cord is OK.

B.

Reseat DIMMs.

C.

Check CPU sockets for bent pins.

D.

Ensure DIMMs are installed in correct slots.

E.

Check the front I/O cable connection to the motherboard.

Question 39

Which Cisco NX-OS command displays kernel uptime?

Options:

A.

show module

B.

show version

C.

show license

D.

show boot

E.

show interface

Question 40

What are the two layers in the SAN hierarchy? (Choose two.)

Options:

A.

Protocol layer

B.

Fabric layer

C.

Connection layer

D.

Switch layer

E.

Storage layer

Question 41

Which method is a TCP/IP-based protocol for establishing and managing connections between IP-based storage devices, hosts, and clients?

Options:

A.

FCIP

B.

iFCP

C.

iSCSI

D.

FCoE

Question 42

Which two specialized tools do you need to service a UCS product? (Choose two.)

Options:

A.

Laptop

B.

Anti-static Strap

C.

KVM Console to USB 2.0 Portable Laptop Crash Cart

D.

Cable Tester

E.

Needle-nose pliers

Question 43

After installation or replacement of a Cisco UCS C-Series Rack-Mount Server, the host does not boot.

Which four options should be verified? (Choose four.)

Options:

A.

Verify the power source to the equipment.

B.

Check for loose HDD cables.

C.

Reseat the DIMMs, CPU, and PCI cards.

D.

Verify that power supplies are receiving power.

E.

Reseat the mezzanine card connector.

F.

Check the CPU sockets for bent pins.

G.

Check the Cisco IMC for fan faults.

Question 44

What is Platform as a Service?

Options:

A.

It configures, manages and develops networking environment for your application.

B.

It is when an application service is delivered over the network on a subscription basis.

C.

It is where servers and virtual machines (VMs), network and storage are delivered over the network on a pay-as-you-go basis.

D.

It is the software development framework and components delivered over the network on a pay-as-you-go basis.

Question 45

Question # 45

Refer to the exhibit. What is the name and function of the icon labeled D?

Options:

A.

Favorite Icon to make any specific work pane in the application a favorite

B.

Index Icon to view listings in alphabetical order

C.

Pin Icon to prevent Navigation pane from sliding

D.

Menu Icon to view the Navigation pane

Question 46

Which Cisco Nexus 5000 Series model supports 1/10G BASE-T ports?

Options:

A.

Cisco Nexus 5548P

B.

Cisco Nexus 5548UP

C.

Cisco Nexus 5596UP

D.

Cisco Nexus 5596T

Question 47

Which cable is used to access the command-line interface of a Cisco UCS 6120XP Fabric Interconnects?

Options:

A.

KVM cable

B.

console cable

C.

Ethernet cable

D.

SFP+ Ethernet transceiver cable

Question 48

Which SAN protocol uses Ethernet network without IP encapsulation?

Options:

A.

IFCP

B.

FCP

C.

iSCSI

D.

FCoE

E.

FC

Question 49

Refer to the exhibit.

Question # 49

Which three options are features of the Cisco UCS 6248UP Fabric Interconnect front panel? (Choose three.)

Options:

A.

Console port

B.

FCoE port

C.

10 Gb/s port

D.

Fan module

E.

USB port

Question 50

When replacing a standalone C-Series server which order will be used to shut down the server via CIMC?

Options:

A.

Click Power off, Click Shut off

B.

Click Power off, Click Shut down

C.

Click Host power, Click Shut off

D.

Click Host power, Click Shut down

Load More 010-151 Questions
Page: 1 / 17
Total 169 questions
Get 010-151 Full Access Download 010-151 PDF
